ZEBRA DS3608 HD SCANNER
Zebra's exclusive PRZM Intelligent Imaging technology delivers first-time capture of high-density 1D and 2D barcodes printed on labels or directly on product components-including tiny and dense 3 mil codes that are barely visible to the naked eye. The DS3600-HD also captures standard printed barcodes in virtually any condition-damaged, dirty, poorly printed or under shrinkwrap. This dual functionality allows you to use the same scanner on the production line for end-to-end track and trace of materials-and in the warehouse from receiving to shipping.
Zebra ultra-rugged scanners earned their name for a reason-you won't find a tougher family of scanners. Ready for the world's harshest environments, the DS3600-HD has the highest drop, tumble and sealing specifications in its class. It can survive 10 ft./3 m drops to concrete and 7,500 tumbles. With dual IP65/IP68 sealing, the DS3600-HD is dust proof, can handle the force of jetting water and be fully submerged in water. Built to withstand extreme heat, cold and humidity, the DS3600-HD can be used anywhere-indoor, outdoor and even in the freezer.
Dimension: | Corded: 7.3 in. H x 3.0 in. W x 5.2 in. D
18.5 cm H x 7.6 cm W x 13.2 cm D Cordless: 7.3 in. H x 3.0 in. W x 5.6 in. D 18.5 cm H x 7.6 cm W x 14.2 cm D |
---|---|
Weight | Corded: 10.9 oz./309 g Cordless: 14.5 oz./411 g |
Input Voltage Range | Host powered: 4.5 VDC min., 5.5 VDC max. External power supply: 11.4 VDC min., 12.6 VDC max. |
Operating Current | DS3608-HD (corded): 360 mA (RMS typical) |
Standby Current | DS3608-HD (corded): 100 mA (RMS typical) |
Color | Industrial Green | Supported Host Interfaces | USB, RS232, Keyboard Wedge Industrial Ethernet: EtherNet/IP, Profinet, Modbus TCP & Std TCP/IP |
Battery | PowerPrecision+ 3100 mAh Li-Ion rechargeable battery |
User Indicators | Direct decode indicator; LEDs; beeper; vibration |
Scans per Full Charge | 100,000+ |
---|---|
Image Capture | Basic |
Illumination | Two (2) warm white light LEDs | Aimer | 655 nm laser |
Imager Field of View | Horizontal: 31, Vertical: 23 |
Image Sensor | 1,280 x 960 pixels | Minimum Print Contrast | 15% minimum reflective difference |
Skew/Pitch/Roll | Skew: 60 Pitch: 60 Roll: 360 |
Operating Temp | Corded: -22 F to 122 F/-30 C to 50 C Cordless: -4 F to 122 F/-20 C to 50 C |
---|---|
Storage Temp | -40 F to 158 F/-40 C to 70 C |
Humidity | 5% to 95% condensing | Drop Specification | Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete |
Drop Spec. | DS3678: Withstands multiple 8.0 ft/2.4 m drops to concrete at -20 C to 50 C |
Tumble Spec. | 7500 3.3 ft./1.0 m tumbles | Sealing | IP65 per applicable IEC sealing specifications |
Ambient Light Immunity | 0 to 10,037 Foot Candles/0 to 108,000 Lux (direct sunlight) |
Scanner Window | Corning Gorilla Glass |
Electrostatic Discharge (ESD) | Per EN61000-4-2, 25 KV air discharge, 10 KV direct discharge, 10 KV indirect discharge |
